Manage the Docker Swarm nodes – new Ansible 2.8 modules developed by me!

There are several good things about open source projects. But there is one which makes the good projects grow quickly – if you miss a feature and you have some programming skills you can write your extension. Then you can propose the change to get merged into the official repository. This is how my journey as a community Ansible developer started.

Lately, I worked more and more with Docker Swarm clusters and wanted to automate some tasks. Unfortunately, with the Ansible 2.7 there were only three modules available – thedocker_swarm, docker_swarm_serviceanddocker_secret. The tasks I wanted to automate required features as reading the Swarm configuration (this was partially covered by the docker_swarm), node status and change the node configuration. I had three options – use the shell module and execute the CLI command locally on the remote host, wait for someone to provide the module or write the module by myself.

I may not be a professional developer, but I had a great teacher when I started coding in the last class of primary school and some experience in programming. You can’t really be an engineer if you cannot write scripts or simpler apps. I think it is not a surprise I decided to test myself in professional project 😛

In the previous post, I presented the docker_swarm_facts module. I am a co-author there. Let me now show you the Swarm Node related modules fully developed and now maintained by me. All of them will be available in Ansible 2.8 release in next few weeks, but you can test it using the devel branch code on GitHub!

Tell me about my Docker Swarm node…

Before you start changing the configuration of any device, software etc. you really should get and store some information about its current state. To read the essentials about the Docker Swarm node you need to use the docker_node_facts module. The module inherits all default docker modules options like the TLS configuration. You can execute it locally using the Docker socket or remotely using the Docker API. Remember that Docker by default use an only local socket so you need to reconfigure your daemon to support remote management. And one of the most important requirements – you need to run the module on Docker Swarm Manager node.

    - name: Get the swarm node facts
        self: yes
        docker_host: "tcp://"
        tls: true

By default, Ansible will open an SSH connection to the remote host and execute the module there connecting to local Docker socket. The host is usually an inventory entry. Using the API requires providing the URL of the management interface as the docker_host parameter. You can execute the module still on the remote host (the same as in docker_host or different), but usually, in such case, the playbook is set with the parameter connection: local and run on the localhost. Understanding this difference is crucial for running any Swarm module and avoid problems.

You also need to tell the module information on which Swarm node you want the manager to return. The default behavior is returning facts about all Swarm nodes. If you know the names of the nodes you are interested in you can provide them as a list in the name parameter. Setting the self: yes option will tell the module you want facts only about the node module communicates with.

Module output matches the output of the docker node inspect CLI command. The nodes key in the returned structure contains an array of dictionaries where each element matches the CLI command. Its structure may vary depending on the version of Docker daemon and Docker API – you need to check the documentation for details.

Changing the node configuration

The docker_node module allows changing some parameters of the Swarm node configuration like the node role or the availability. The first parameter defines if the node is a manager or a worker. Initially, you must define the role when you add a node to the cluster. The availability defines how the swarm cluster will use the node for work distribution. Three allowed states are active (accepting new containers), pause (operating the existing containers but not accepting new ones) or drain (not accepting new containers and existing will restart on another node). The last state is useful during upgrades or when you want to remove a node from the cluster

The docker_node module also allows changing the labels assigned to the Swarm node. Labels are usefull for management and automated work distribution. Labels are the key-value pairs. The default module behavior is merging the labels provided in playbook with those already assigned to node and update the value of a label if it is already defined.

- name: Merge node labels and new labels
    hostname: mynode
      key: value

To override default behavior and replace the labels with new ones you must set labels_state: replace. To remove all assigned labels you also have to use this option, but without providing any new labels.

- name: Remove all labels assigned to node
    hostname: mynode
    labels_state: replace

If you want to remove specified labels you need to provide the list of label keys in parameter labels_to_remove.
